The VOLTWING SOLID-LINE by BERNEGGER is a modular system based on prefabricated concrete parts MADE IN AUSTRIA for the roofing of cars with a fully cantilevered system.
A special highlight is the integrated foundation that can be installed with minimal ground intervention.

PV-CARPORT with integrated concrete-based foundation

One highlight of the VOLTWING SOLID is certainly the simple foundation. This is manufactured from a single source by Bernegger and features minimal ground intervention and a rapid overall installation time. In addition, the empty pipework and earthing are already integrated into the component.

Project sequence: First, narrow strips are cut into the asphalt and excavated. The precast concrete elements – which are delivered without special transportation – are then brought to the construction site and lifted into place with the loading crane. The prefabricated parts are positioned using the special Bernegger ground anchoring system and then cast. Once the columns have been completed, the VOLTRAIL roof system is installed.
