VOLTWING ECO – maximum economy MADE in GERMANY
Solar carports for large parking spaces
The new VOLTWING ECO LINE combines production excellence with carport expertise and combines the highest quality MADE IN GERMANY with maximum product flexibility:
VOLTWING ECO is a highly modular system for roofing parking spaces with photovoltaics based on galvanized steel profiles.
3 models for every floor plan – how flexibility works
The VOLTWING ECO line consists of 3 models that can be used alone or in combination to cover any floor plan. They can be used regardless of the orientation and any green and drainage strips.
Solar carport models
VOLTWING ECO-5F
Combi ECO-5 and ECO-5
Combi ECO-5F and ECO-5H
VOLTWING ECO-5
Technical data of VOLTWING ECO
Advantages of VOLTWING ECO carports
We consider the entire life cycle of our products – from planning to installation
You are currently viewing a placeholder content from Vimeo. To access the actual content, click the button below. Please note that doing so will share data with third-party providers.
More InformationSimple foundation with screws
Minimal ground intervention and quick installation – this is what characterizes the Schaub foundation for the VOLTWING ECO models. Unbeatable, especially in existing buildings – a core hole is drilled into the asphalt through which the ground screw is screwed in. After screwing in, the foundation can be loaded immediately. Without excavators, mixer trucks or excavation logistics.
You are currently viewing a placeholder content from Vimeo. To access the actual content, click the button below. Please note that doing so will share data with third-party providers.
More InformationVariable lengths and parking space widths
Every parking space is different. All VOLTWING PV carports can therefore be extended in steps of approximately 1 meter (module width) – so any length can be mapped. In order to accommodate different parking space widths – such as disabled parking spaces or e-charging spaces – the width of the columns can be infinitely varied. Innovative and practical.
You are currently viewing a placeholder content from Vimeo. To access the actual content, click the button below. Please note that doing so will share data with third-party providers.
More InformationSlope compensation
Thanks to the integrated slope compensation, the roof follows the original terrain and thus saves expensive, project-specific individual parts and enables a constant driveway height over the entire length.
You are currently viewing a placeholder content from Vimeo. To access the actual content, click the button below. Please note that doing so will share data with third-party providers.
More InformationHigh comfort
We always use cantilevered roofs for our constructions. The main difference to multi-support constructions is the high level of parking comfort. In addition, a vehicle collision is very unlikely. Another advantage is the preservation of the parking area, as the parking space width can remain the same and does not have to be increased to enable parking.
You are currently viewing a placeholder content from Vimeo. To access the actual content, click the button below. Please note that doing so will share data with third-party providers.
More InformationIntegrated solutions
Whether charging technology or lighting – the VOLTWING ECO modular system can be combined in a variety of ways. LED lighting can be integrated into the supporting structure, as can AC charging stations. DC chargers can be combined free-standing, regardless of the manufacturer.
Here you will find detailed information on planning Voltwing carports.
You are currently viewing a placeholder content from Vimeo. To access the actual content, click the button below. Please note that doing so will share data with third-party providers.
More InformationPlanning tool and ready-made documents
We love lean processes – and architects and planners should also benefit from this. That’s why VOLTWING PV carports come with a library for ArchiCAD, a planning guide, ready-made submission documents, structural calculations, detailed solutions, etc. – Everything to make planning the system as simple and efficient as possible and to save you from having to discuss the details of every new project.
Maximum efficiency and quality
The VOLTWING ECO line developed by us is intended to set new standards in the field of price-sensitive roofing for large parking lots with photovoltaics. Read here about the key benefits for project planners, investors and end customers:
All-round carefree
Work with the professionals and rely on established companies that understand your needs, are accessible and speak your language. We have also installed all the systems ourselves – we are happy to share our experience with you and train your team so that you can work more efficiently.
Quality at the best price
The VOLTWING ECO line is a modular system consisting of just a few components manufactured by MEISER SOLAR in Saarland. MEISER processes over 350,000 tons of steel every year. These are the perfect ingredients for scaling, volume effects and therefore quality at the best price.
Fast availability
Another advantage of the modular system. The few basic components can be stored economically and are therefore quickly available.
Maximum flexibility
Our carports adapt to the parking space – not the parking space to the carport. Thanks to the flexible column position and compatibility with standard PV modules, this sophisticated series product is almost as flexible as you would expect from a project-specific individual solution.
Fast and error-resistant installation
Large-scale projects are all about time and avoiding errors. Right from the start, we focused on quick and easy installation during development. Where others still have to measure and mark, you can assemble using the holes that have already been punched.
Simple planning
The efficient handling of photovoltaic roofing projects begins in the planning phase. The modular system is very flexible and enables fast, site-specific planning with a high degree of cost certainty. In addition, we have integrated the modular system into the ArchiCAD planning program so that the correct dimensions can be used as early as the project submission stage and time-consuming replacement planning can be avoided during the project.
